| R41002-0A500 |
| R41002-0A160 |
| R41002-0A200 |
| R41002-0A250 |
| R41002-1A00 |
| R41002-1A25 |
| R41002-1A60 |
| R41002-6A30 |
| R41002-8A00 |
| R41002-10A0 |
| EDCON-COMPONENTS | |||||||
| GLASS FUSE 5,0x20mm Slow Blow Serie R41002 | |||||||
| PDF Datasheet | Ampere Rating | Voltage | Nominal Resistance Cold Ohms | Voltage Drop (mV) Max. | Nominal Melting I²t A²Sec. | ||
|
0,050 A | 250V | 0,0000 | 0 | 0,000000 | ||
| R41002-0A063 | 0,063 A | 250V | 19,0000 | 1900 | 0,010800 | ||
| R41002-0A080 | 0,080 A | 250V | 14,0000 | 1850 | 0,024400 | ||
| R41002-0A100 | 0,10 A | 250V | 10,5000 | 1800 | 0,052000 | ||
| R41002-0A125 | 0,125 A | 250V | 8,7000 | 1800 | 0,091000 | ||
|
0,16 A | 250V | 6,2000 | 1700 | 0,100000 | ||
|
0,20 A | 250V | 3,7000 | 1500 | 0,242400 | ||
|
0,25 A | 250V | 2,9600 | 1300 | 0,545000 | ||
| R41002-0A315 | 0,315 A | 250V | 1,8400 | 1000 | 1,133000 | ||
| R41002-0A400 | 0,40 A | 250V | 1,3200 | 900 | 1,538000 | ||
| R41002-0A500 | 0,50 A | 250V | 0,2015 | 300 | 0,525000 | ||
| R41002-0A630 | 0,63 A | 250V | 0,1420 | 250 | 1,151000 | ||
| R41002-0A800 | 0,80 A | 250V | 0,1085 | 230 | 2,240000 | ||
|
1,00 A | 250V | 0,0780 | 150 | 2,400000 | ||
|
1,25 A | 250V | 0,0570 | 140 | 7,500000 | ||
|
1,60 A | 250V | 0,0410 | 130 | 6,144000 | ||
| R41002-2A00 | 2,00 A | 250V | 0,0340 | 120 | 8,800000 | ||
| R41002-2A50 | 2,50 A | 250V | 0,0240 | 110 | 15,000000 | ||
| R41002-3A15 | 3,15 A | 250V | 0,0180 | 100 | 29,760000 | ||
| R41002-4A00 | 4,00 A | 250V | 0,0140 | 100 | 56,000000 | ||
| R41002-5A00 | 5,00 A | 250V | 0,0120 | 100 | 70,000000 | ||
|
6,30 A | 250V | 0,0082 | 100 | 198,400000 | ||
|
8,00 A | 250V | 0,0055 | 100 | 345,600000 | ||
|
10,0A | 250V | 0,0048 | 63 | 676,000000 | ||
| R41002-12A0 | 12,0A | 250V | 0,0046 | 82 | 755,000000 | ||
| R41002-12A5 | 12,5A | 250V | 0,0044 | 80 | 821,000000 | ||
| R41002-15A0 | 15,0A | 250V | 0,0036 | 78 | 1442,000000 | ||
| R41002-16A0 | 16,0 A | 250V | 0,0032 | 78 | 1626,000000 | ||
