For the next step
of selection please click on the Link to Serie with your mouse off the white letters |
|
|
|
|
|
|
|
|
|
| |
|
THT Radial |
|
|
|
|
|
| Link
to Serie |
Description |
Lifetime |
Temp.-Range |
V-Range |
Cap-Range |
|
| I14001 |
THT Rad 5mm Height |
2000Hrs |
.-40°C ~ +85°C |
4V ~ 63V |
0,1µF ~ 470µF |
UMA |
| I14002 |
THT Rad 5mm Height /
Higher Temperature |
1000Hrs |
.-40°C ~ +105°C |
6,3V ~ 50V |
0,1µF ~ 100µF |
|
| I14003 |
THT Rad 5mm Height /
Bipolar |
1000Hrs |
.-40°C ~ +85°C |
6,3V ~ 50V |
0,1µF ~ 47µF |
|
| I14004 |
THT Rad 7mm Height |
1000Hrs |
.-40°C ~ +85°C |
4V ~ 63V |
0,1µF ~ 470µF |
|
| I14005 |
THT Rad 7mm Height /
Higher Temperature |
1000Hrs |
.-40°C ~ +105°C |
6,3V ~ 50V |
0,1µF ~ 100µF |
|
| I14006 |
7mm Height NON-Polar |
2000Hrs |
.-40°C ~ +85°C |
6,3V ~ 50V |
0,1µF ~ 47µF |
|
| I14008 |
Standard Radial |
2000Hrs |
.-40°C ~ +85°C |
6,3V ~ 500V |
1µF ~ 22000µF |
SAII |
| I14009 |
Standard Radial |
2000Hrs |
.-40°C ~ +105°C |
6,3V ~ 500V |
1µF ~ 22000µF |
SH |
| I14011 |
Standard Radial / Bipolar |
2000Hrs |
.-40°C ~ +85°C |
6,3V ~ 100V |
0,1µF ~ 4700µF |
SBP |
| I14054 |
Low Impedance / Wide
Voltage |
2000~5000Hrs |
.-40°C ~ +105°C |
6,3V ~ 500V |
1µF ~ 15000µF |
SHK |
| I14056 |
Ultra Low Impedance /
High Ripple |
2000~5000Hrs |
.-40°C ~ +105°C |
6,3V ~ 100V |
1µF ~ 15000µF |
SHM |
| I14057 |
Ultra Low Impedance /
High Ripple |
2000~5000Hrs |
.-40°C ~ +105°C |
6,3V ~ 100V |
1µF ~ 15000µF |
SHY |
| I14058 |
Ultra Low Impedance /
High Ripple |
2000~5000Hrs |
.-40°C ~ +105°C |
10V ~ 35V |
35µF ~ 3300µF |
SHE |
| I14059 |
Ultra Low Impedance /
High Ripple / Long Life |
6000~10000Hrs |
.-40°C ~ +105°C |
6,3V ~ 100V |
10µF ~ 10000µF |
SHX |
| I14060 |
Ultra Low Impedance /
High Ripple / Long Life |
7000~12000Hrs |
.-40°C ~ +105°C |
6,3V ~ 50V |
10µF ~ 10000µF |
SHJ |
| I14061 |
For LED Lighting / Long
Life |
2000Hrs |
.-40°C ~ +105°C |
10V ~ 35V |
100µF ~ 4700µF |
SG |
| I14062 |
For LED Lighting / Long
Life / Miniature |
10000Hrs |
.-25°C ~ +105°C |
10V ~ 100V |
1µF ~ 330µF |
SY |
| I14063 |
For LED Lighting / Low
Impedance / High Ripple |
6000~10000Hrs |
.-40°C ~ +105°C |
6,3V ~ 120V |
27µF ~ 8200µF |
SQ |
| I14064 |
For PSU / High Ripple |
5000Hrs |
.-40°C ~ +105°C |
160V ~ 500V |
1,0µF ~ 220µF |
BS |
| I14065 |
For PSU / High Ripple /
Long Life |
10000Hrs |
.-40°C ~ +105°C |
160V ~ 500V |
1,0µF ~ 150µF |
BT |
| I14066 |
For PSU / High Ripple /
Long Life |
12000Hrs |
.-40°C ~ +105°C |
160V ~ 500V |
1,0µF ~ 470µF |
BD |
| I14067 |
For PSU / High Ripple /
Long Life |
15000Hrs |
.-40°C ~ +105°C |
160V ~ 500V |
10µF ~ 470µF |
BB |
| I14068 |
For PSU / High Ripple /
Long Life |
20000Hrs |
.-40°C ~ +105°C |
160V ~ 500V |
3,3µF ~ 470µF |
BC |
| I14069 |
High Temperature Range |
1000~2000Hrs |
.-40°C ~ +125°C |
6,3V ~ 250V |
1,0µF ~ 15000µF |
SHT |
| I14070 |
High Temperature Range /
Long Life |
2000~5000Hrs |
.-40°C ~ +125°C |
6,3V ~ 100V |
22µF ~ 3300µF |
SHW |
| I14071 |
For PSU / High
Temperature |
5000Hrs |
.-25°C ~ +130°C |
160V ~ 500V |
2,2µF ~ 47µF |
BK |
| I14072 |
High Temperature |
1000~3000Hrs |
.-40°C ~ +135°C |
10V ~ 100V |
4,7µF ~ 4700µF |
BW |
| I14073 |
High Temperature |
1000~2000Hrs |
.-40°C ~ +150°C |
10V ~ 400V |
2,2µF ~ 4700µF |
BX |
| I14074 |
Bi-Polar for Audio
Equipment |
1000Hrs |
.-40°C ~ +85°C |
6,3V ~ 50V |
1µF ~ 1000µF |
ES |
| I14075 |
Bi-Polar for Speaker
Network |
1000Hrs |
.-40°C ~ +85°C |
50V |
1µF ~ 47µF |
DB |
| I14076 |
High Ripple Current /
Extremly Low Impedance |
10000hHs |
.-40°C ~ +105°C |
6,3V ~ 100V |
0,47µF ~ 15000µF |
SHF |
| I14107 |
5mm Height NON-Polar |
1000Hrs |
.-40°C ~ +85°C |
6,3V ~ 50V |
0,1µF ~ 47µF |
UMP |
| I14108 |
5mm Height Low Impedance |
1000Hrs |
.-55°C ~ +105°C |
6,3V ~ 35V |
1,0µF ~ 100µF |
SKZ |
| I14110 |
Extemly Low Impedance
Serie |
10000Hrs |
.-40°C ~ +105°C |
6,3V ~ 50V |
1,0µF ~ 15000µF |
SHG |
| I14111 |
Extemly Low Impedance
Serie |
2000Hrs |
.-40°C ~ +105°C |
6,3V ~ 500V |
0,22µF ~ 15000µF |
SHL |
| I14112 |
Extemly Lower Impedance
Serie |
5000Hrs |
.-40°C ~ +105°C |
6,3V ~ 100V |
0,47µF ~ 15000µF |
SHQ |
| I14113 |
Extemly Lower Impedance
Serie |
10000Hrs |
.-40°C ~ +105°C |
6,3V ~ 100V |
0,47µF ~ 15000µF |
SHR |
| I14114 |
For SLIM PSU
Serie |
2000Hrs |
.-40°C ~ +105°C |
250V ~ 500V |
15µF ~ 150µF |
SHU |
| I14115 |
For SLIM PSU
Serie |
10000Hrs |
.-40°C ~ +105°C |
250V ~ 500V |
15µF ~ 150µF |
SHV |
| I14116 |
Low Leackage Current Serie |
2000Hrs |
.-40°C ~ +85°C |
10V ~ 100V |
1,0µF ~ 4700µF |
SLL |
| I14117 |
Standard 7mm Height Serie |
2000Hrs |
.-40°C ~ +85°C |
4V ~ 63V |
0,1µF ~ 220µF |
SMA |
| I14118 |
7mm Height NON-Polar |
2000Hrs |
.-40°C ~ +85°C |
6,3V ~ 50V |
0,1µF ~ 47µF |
SMP |
| I14119 |
For Speaker
Networks Serie |
2000Hrs |
.-40°C ~ +85°C |
50V, 100V, 200V |
1,0µF ~ 100µF |
SNP |
| I14121 |
5mm Height Wide
Temperature Range Serie |
1000Hrs |
.-40°C ~ +105°C |
4,0V ~ 50V |
0,1µF ~ 220µF |
UHA |
| I14134 |
Non Polarized, Wide
Temperature Range |
1000Hrs |
.-40°C ~ +105°C |
6,3V ~ 100V |
0,1µF ~ 6800µF |
HBP |
|
|
|
|
|
|
|
|
THT Axial |
|
|
|
| Link
to Serie |
Description |
Lifetime |
Temp.-Range |
V-Range |
Cap-Range |
|
| I14135 |
For General Electronic Equipments |
2000Hrs |
.-40°C ~ +85°C |
6,3V ~ 160V |
0,47µF ~ 1000µF |
CD95 |
| I14132 |
For Audio -
-Crossover - Networks Speaker |
2000Hrs |
.-40°C ~ +85°C |
6,3V ~ 160V |
0,47µF ~ 1000µF |
AKP |
| I14133 |
For Audio - -Crossover - Networks |
2000Hrs |
.-40°C ~ +85°C |
6,3V ~ 160V |
0,47µF ~ 1000µF |
ANP |
|
|
|
|
|
|
|
|
THT Polymer Radial |
|
|
|
|
|
| Link
to Serie |
Description |
Lifetime |
Temp.-Range |
V-Range |
Cap-Range |
|
| I14048- NOT Online |
Polymer High-Ripple / Ultra Low ESR |
|
.-55°C ~ +105°C |
2,5V ~ 10VDC |
220µF ~ 1500µF |
SV |
| I14049-NOT Online |
Polymer High-Ripple / Ultra Low ESR / High-Frequency |
|
125°C Guaranted |
2,5V ~ 100VDC |
4,7µF ~ 1500µF |
ST |
| I14050-NOT Online |
Large Permissible Current / Low ESR / High-Frequency |
|
.-55°C ~ +105°C |
2,5V ~ 25VDC |
220µF ~ 3300µF |
SS |
| I14051-NOT Online |
Large Permissible Current / Low ESR / High-Frequency |
|
.-55°C ~ +105°C |
2,5V ~ 25VDC |
180µF ~ 1500µF |
SR |
| I14052-NOT Online |
Large Permissible Current / Low Profile / Low ESR |
|
.-55°C ~ +105°C |
2,5V ~ 100VDC |
4,7µF ~ 1500µF |
SL |
| I14053-NOT Online |
High Ripple-Current / High-Temperatur |
|
.-55°C ~ +135°C |
35V ~ 100VDC |
4,7µF ~ 1000µF |
SK |
| I14104-NOT Online |
Large permible Current / LOW ESR / High Frequency |
|
.-55°C ~ +105°C |
30V ~ 100VDC |
4,7µF ~ 1000µF |
SH |
| I14105-NOT Online |
Large permible Current / LOW ESR / High Frequency |
|
.-55°C ~ +105°C |
160V ~ 250VDC |
1,0µF ~ 12µF |
SG |
| I14106-NOT Online |
Super Long Life / Low ESR / High-Frequency |
|
.-55°C ~ +105°C |
2,5V ~ 25VDC |
220µF ~ 1500µF |
SF |
|
|
|
|
|
|
|
|
SNAP-IN |
|
|
|
|
|
| |
Description |
Lifetime |
Temp.-Range |
V-Range |
Cap-Range |
|
| I14078 |
Standard SNAP-In |
2000Hrs |
.-40°C ~ +85°C |
6,3V ~ 550V |
47µF ~ 100000µF |
LS |
| I14079 |
Standard SNAP-In / Long
Life |
3000Hrs |
.-40°C ~ +85°C |
10V ~ 500V |
56µF ~ 56000µF |
LJ |
| I14080 |
Long Life / High-Voltage |
3000Hrs |
.-25°C ~ +85°C |
575V ~ 630V |
150µF ~ 820µF |
LN |
| I14081 |
Long Life / High-Voltage |
5000Hrs |
.-40°C ~ +85°C |
160V ~ 450V |
56µF ~ 3300µF |
JA |
| I14082 |
Wide Temperatur-Range |
2000Hrs |
.-40°C ~ +105°C |
6,3V ~ 550V |
47µF ~ 100000µF |
LT |
| I14083 |
Wide Temperatur-Range /
Long Life |
3000Hrs |
.-40°C ~ +105°C |
6,3V ~ 500V |
68µF ~ 68000µF |
LM |
| I14084 |
Wide Temperatur-Range /
Long Life / High Ripple |
3000Hrs |
.-40°C ~ +105°C |
400V ~ 450V |
68µF ~ 470µF |
JB |
| I14085 |
Wide Temperatur-Range /
Long Life |
5000Hrs |
.-40°C ~ +105°C |
10V ~ 500V |
68µF ~ 56000µF |
LL |
| I14086 |
Wide Temperatur-Range /
Long Life |
7000Hrs |
.-40°C ~ +125°C |
160V ~ 500V |
56µF ~ 1800µF |
LX |
| I14087 |
Wide Temperatur-Range /
Long Life |
10000Hrs |
.-25°C ~ +105°C |
400V ~ 450V |
47µF ~ 470µF |
LY |
| I14088 |
Permissible Overvoltage |
2000Hrs |
.-40°C ~ +105°C |
200V ~ 450V |
82µF ~ 2200µF |
LC |
| I14089 |
High Speed Charge -
Discharge |
3000Hrs |
.-25°C ~ +105°C |
350V ~ 450V |
82µF ~ 820µF |
LD |
| I14090 |
High Temperature Range |
1000Hrs |
.-40°C ~ +125°C |
10V ~ 250V |
100µF ~ 15000µF |
LB |
| I14122 |
Long Life, Low
Impedance Serie |
3000Hrs |
.-40°C ~ +105°C |
10V ~ 450V |
47µF ~ 33000µF |
LE |
| I14123 |
Long Life Serie |
3000Hrs |
.-40°C ~ +85°C |
10V ~ 450V |
47µF ~ 56000µF |
LE |
| I14124 |
Long Life Serie |
5000Hrs |
.-40°C ~ +105°C |
10V ~ 500V |
47µF ~ 56000µF |
LQ |
| I14125 |
Long Life, Low
Impedance Serie |
5000Hrs |
.-40°C ~ +105°C |
10V ~ 450V |
47µF ~ 33000µF |
LR |
| I14126 NOT Online |
LUG Terminals Power
Supplies, Industrail-Controls |
2000Hrs |
.-40°C ~ +85°C |
16V ~ 450V |
68µF ~ 100000µF |
LU |
| I14127 |
Long Life Serie |
3000Hrs |
.-40°C ~ +105°C |
10V ~ 500V |
47µF ~ 56000µF |
LV |
| |
|
|
|
|
|
|
| |
SCREW-Type |
|
|
|
|
|
| Link to Serie |
Description |
Lifetime |
Temp.-Range |
V-Range |
Cap-Range |
|
| I14128 NOT Online |
High Temperature
Screw-Terminal |
3000Hrs |
.-25°C ~ +125°C |
160V ~ 400V |
330µF ~ 15000µF |
WB |
| I14129 NOT Online |
High Ripple Current, Screw-Terminal |
2000Hrs |
.-25°C ~ +85°C |
350V ~ 450V |
390µF ~ 22000µF |
WI |
| I14130 NOT Online |
Long Life Assurance,
Screw-Terminal |
5000Hrs |
.-40°C ~ +85°C |
10V ~ 550V |
4700µF ~ 1500000µF |
WK |
| I14131 NOT Online |
High Ripple Current, High
Reliability Serie, Screw-Terminal |
5000Hrs |
.-40°C ~ +105°C |
10V ~ 525V |
330µF ~ 39000µF |
WQ |
|
|
|
|
|
|
|
| I14096
NOT Online |
(Screw) Standard Type |
1000Hrs |
.-40°C ~
+85°C |
10V ~ 650V |
270µF ~
82000µF |
WS |
| I14097 NOT Online |
(Screw) Standard Type /
Long Life |
5000Hrs |
.-40°C ~ +85°C |
350V ~ 450V |
1000µF ~ 18000µF |
WJ |
| I14098 NOT Online |
(Screw) Standard Type /
Long Life / Smaller Size |
5000Hrs |
.-40°C ~ +85°C |
400V ~ 550V |
1000µF ~ 22000µF |
WM |
| I14099 NOT Online |
(Screw) Ultra-Long-Life |
10000Hrs |
.-40°C ~ +85°C |
350V ~ 500V |
1500µF ~ 12000µF |
WH |
| I14100 NOT Online |
(Screw) Ultra-Long-Life |
20000Hrs |
.-40°C ~ +85°C |
350V ~ 500V |
1000µF ~ 12000µF |
WL |
| I14101 NOT Online |
(Screw) Wide
Temperature-Range |
2000Hrs |
.-40°C ~ +105°C |
25V ~ 450V |
220µF ~ 33000µF |
WT |
| I14102 NOT Online |
(Screw) Wide
Temperature-Range / Long-Life |
5000Hrs |
.-40°C ~ +105°C |
350V ~ 450V |
1000µF ~ 15000µF |
WP |
| I14103 NOT Online |
(Screw) Wide
Temperature-Range / Long-Life / Hgih-Ripple |
5000Hrs |
.-40°C ~ +105°C |
350V ~ 450V |
1000µF ~ 15000µF |
WR |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
